| Colour System: |
Laser Phosphor |
| DMD Specification: |
Single chip 0.48" DMD |
| Aspect Ratio: |
16x10 |
| Fill Factor |
|
| Key Features: |
Video & Graphics Processing
- HDMI 2.0
- 2 x Digital Zoom
- HSG Color Management
- Sealed Engine
- Auto Power On / Off
Geometry Correction & Lenses info
- Keystone Adjustment 2D : V/H: +/- 15 steps ( ±15 Degree)
- 4 Corner - 60 Steps
- Image offset 122% (+/- 5%)
Colour Processing
- 4 Segment (RGBY) / 2X Color Wheel
- >90% Rec709
|
| Source Compatibility |
Graphics standards up to 1920 x 1200 resolution at 60Hz.
Input support for 4K-UHD, 3840 x 2160 |
| Inputs/Outputs |
| Video & Computer |
| Type |
Connector |
Qty |
VGA-In
HDMI 2.0 |
VGA-In (15pin D-Sub)
HDMI 2.0 |
1
2 |
.
| Communication & Control |
| Type |
Connector |
Qty |
Lan (RJ45)
DC 12v Trigger (3.5mm Jack )
RS-232 In |
RJ45
3.5mm Jack
RS232
|
1
1
1 |
|
| 3D Formats Supported |
3D ready (DLP link, PC + Video),
3D Mandatory formats supported ( Top/bottom, Side by Side, Frame Sequential). |
| HDTV Formats Supported |
720p, 1080i and 1080p |
| Computer Compatibility |
VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA |
| Bandwidth |
|
| Remote Control |
IR remote control |
| Automation Control |
Alert Mail for Projector
LAN Control-Crestron Roomview-Connected
LAN Control-Crestron eControl
LAN control - Extron
LAN Control-PJ Link compatible
LAN Control-AMX SSDP
LAN to RS232 (RS232 by Telnet) |
| Colour Temperature |
|
| Operation |
 |
| illumination Type |
Laser Light Source |
| Typical illumination Life |
15,000 hours |
| Lenses |
| Lens |
Part No. |
Optimised Focus Range* |
Lens Shift (Frame) |
| 0.25:1 (fixed) |
N/A |
0.336m - 0.739m |
N/A |
* Lens focal ranges above are the optimised distances but are likely to focus further, please contact your RSM for more details. Lens ratio tolerances: E-Vision Series: +/-3%. HighLite Series: +/- 5%. M-Vision Series: +/- 2%. Titan Series: +/-2%, INSIGHT Series: +/-2%,
|
| Lens Mount |
Manual focus |
| Mechanical Mounting |
Front/Rear
Front/Rear Ceiling
Two adjustable front feet
Ceiling Mount compatible chassis with 4 off M4 mounting holes |
| Orientation |
Table Top or Inverted: Yes
Pointing Up: Yes
Pointing Down: Yes
Roll (Portrait): Yes |
| Power Requirements |
100-240VAC 50/60Hz single phase |
| Power Consumption |
Normal Mode (100%): 370@240VAC
Eco Mode (80%) 290W @240VAC |
| Thermal Dissipation |
Normal Mode (typical):1263 BTU/Hour @ 240VAC
Eco Mode (Typical) 990 BTU/Hour at 240VAC |
| Fan Noise |
Normal Mode (Typical): 35 dBA / Eco 33 dBA |
| Operating/Storage Temperature: |
Operating: 0° to 40°C (32°F to 104°F)
Storage: -20° to 60°C (-4°F to -140°F)
|
| Operating Humidity |
10% to 85% non-condensing |
| Weight |
9 kg / 19.8 lbs |
| Dimensions |
L: 405 mm W: 380 mm H: 150 mm (Excluding feet)
L: 15.94 in W: 14.96 in H: 5.9 in |
| Safety & EMC Regulations |
FCC Class B, CE, CB, RoHS, |
| Accessories |
*Dimensions included for reference only and are subject to change. Please download the full set of CAD files for this display for more accurate information.
|
